FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature

Name: FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: FeCrAl255
Price: 26.00 USD
Availability: InStock

Ürün Detayları

Menşe yeri: Çin

Marka adı: Tankii

Sertifika: ISO9001

Model numarası: FeCrAl255

Ödeme ve Gönderim Koşulları

Min sipariş miktarı: 10kg

Fiyat: pazarlık edilebilir

Ambalaj bilgileri: Makara

Teslim süresi: 15-20 gün

Ödeme koşulları: T/T

Yetenek temini: 500 ton/yıl

En İyi Fiyatı Alın

Şimdi İletişime Geçin

Özellikler

Açıklama

Özellikler

Vurgulamak:
                                                                              FeCrAl255 resistance wire 0.2mm, high temp FeCrAl wire for kiln, 25 gauge furnace resistance wire


Açıklama

FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature

Good Quality 0Cr25Al5 Fecral Alloy Wire Heat Resistance for Oven

0Cr25Al5 is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.

Typical applications for 0Cr25Al5 are used in electric ceramic cooktop,industrial furnace,heaters.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.06	0.025	0.025	0.70	Max 0.60	23.0~26.0	Max 0.60	4.5~6.5	Bal.	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
500	700	23

Typical Physical properties

Density (g/cm3)	7.10
Electrical resistivity at 20ºC(ohm mm2/m)	1.42
Conductivity coefficient at 20ºC (WmK)	13

Coefficient of thermal expansion

Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	15

Specific heat capacity

Temperature	20ºC
J/gK	0.46

Melting point (ºC)	1500
Max continuous operating temperature in air (ºC)	1250
Magnetic properties	magnetic

FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature 0
