6J12 Precision Manganin 47 Resistance Wire Excellent Long Term Stability for Standard Resistor & Metrology Measuring Instruments

Ürün Detayları

Menşe yeri: Çin

Marka adı: Tankii

Sertifika: ISO 9001

Model numarası: manganin 47

Ödeme ve Gönderim Koşulları

Min sipariş miktarı: 30kg

Fiyat: negotiate

Ambalaj bilgileri: karton

Teslim süresi: 2-3 hafta

Yetenek temini: Yılda 5000 Ton

En İyi Fiyatı Alın
Şimdi İletişime Geçin
Özellikler
Vurgulamak:
Malzeme:
manganin 47
Modeli:
6J12
Şekil:
tel/şerit/folyo
Yoğunluk:
8,4 gr/cm3
Dayanıklılık:
47μΩ/cm
Uzama:
≥15%
TCR:
-3-+20(*10^﹣6/°C)
EMF ve Cu μV/°C:
≤1
Malzeme:
manganin 47
Modeli:
6J12
Şekil:
tel/şerit/folyo
Yoğunluk:
8,4 gr/cm3
Dayanıklılık:
47μΩ/cm
Uzama:
≥15%
TCR:
-3-+20(*10^﹣6/°C)
EMF ve Cu μV/°C:
≤1
Açıklama
6J12 Precision Manganin 47 Resistance Wire Excellent Long Term Stability for Standard Resistor & Metrology Measuring Instruments
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire

Chemical Content, %
Ni Mn Fe Si Cu Other RoHS Directive
CD Pb Hg Cr
- 10.5-12.5 - - Bal - ND ND ND ND

Mechanical Properties
Max Continuous Service Temp 0-45ºC
Resisivity at 20ºC 0.49±0.03ohm mm2/m
Density 8.g/cm3
Temp Coefficient of Resistance at 20 ºC -80~+80α×10-6/ºC
Melting Point 1450ºC
Tensile Strength(Hard) 635 MPa(min)
Tensile Strength,N/mm2   Annealed,Soft 340~535
Elongation 15%(min)
EMF vs Cu, μV/ºC (0~100ºC) 2
Micrographic Structure Austenite
Magnetic Property Non
Micrographic Structure Ferrite
Magnetic Property Magnetic
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire
(6J8 6J11 6J12 6J13) High Precision Resistance Alloy Wire
